928.0300.00 EG55
Insert
Material number 928030000EG55
HORN Insert 928.0300.00 EG55 for Milling
Cutting diameter (Ds)
27.7
mm
Number of teeth (Z)
9
St.
ISO_SSC
HORN328143$84R$$$$$
DIN_SSC
HORN32814384R
Katalog_SSC
328143R
Width of groove (w)
3
mm
Maximum milling depth/ depth of groove (tmax)
6.5
mm
Cutting insert thickness, setting length complete (s)
6.1
mm
Corner radius (r)
0.2
mm
| Downloads | |
|---|---|
| 928_0300_00_EG55-DXF.DXF | Download |
| 928_0300_00_EG55-STP.STP | Download |
| 928_0300_00_EG55-DIN.XML | Download |
| Download all files | |
