939.0100.4.00 RC25
Insert
Material number 9390100400RC25
HORN Insert 939.0100.4.00 RC25 for Milling
Cutting diameter (Ds)
40
mm
Number of teeth (Z)
9
St.
ISO_SSC
HORN332110$84R$$$$$
DIN_SSC
HORN33211084R
Katalog_SSC
332110R
Width of groove (w)
1
mm
Maximum milling depth/ depth of groove (tmax)
14
mm
Cutting insert thickness, setting length complete (s)
5.8
mm
| Downloads | |
|---|---|
| 939_0100_4_00_RC25-DXF.DXF | Download |
| 939_0100_4_00_RC25-STP.STP | Download |
| 939_0100_4_00_RC25-DIN.XML | Download |
| Download all files | |
