DCR.3.40.10.05.1.06 AN25

DC groove mill cutter - full radii

Material number DCR3401005106AN25

HORN DC groove mill cutter - full radii DCR.3.40.10.05.1.06 AN25 for Milling

ISO_CCTMS

ZYL01F6000h$06

Total length (l1)

50 mm

Radius, full-radius (r)

0.5 mm

Maximum milling depth/ depth of groove (tmax)

0.5 mm

Neck diameter (d3)

2.75 mm

Shank diameter (d2)

6 mm

DIN_CCTMS

ZYL00600105

Shank, clamping length (l4)

36 mm

Width of groove (w)

1 mm

Number of teeth (Z)

3 St.

Cutting diameter (d1)

4 mm

Neck length (l3)

4 mm
